CPD-J series 4-5T Electric Forklift (AC)

Home » Products » Forklift Truck » Four Wheel Electric Forklift » CPD-J series 4-5T Electric Forklift (AC)

1. Towing Tractor
2. Electric Platform Truck

Related Products

1. AC Power System
Multiple benefits of the AC Power System include: fast response to operating commands, precise power control, compact components. Moreover, since the AC motor does not use contactors and brushes, these maintenance items will no longer be required. Operata will be able to feel the difference by the truck's New design and performance.

2. New Multi-Display employed full dotted LCD is located on the steering column to improve visibility and manipulate-ability.

3. SOFT LANDING LIFT CYLINDER
During lowering fork with no load, fork speed is reduced just before touching ground to avoid collision noise with ground. The operator and those working near the forklift will appreciate the reduced noise.

4. The adjustable steering Column ensure a comfortable working position.

5. Comfortable seat can be upgraded to a luxury semi suspension version.

6,Bacause you open and close the battery cover for daily checkup, access of battery cover is improved by using gas-spring with lock function.

7. The CPD-J series four-wheel truck (4.0-5.0T) has three independent braking systems:
Regenerative braking system
Hydraulic wet disc brake system
Toggle-type parking brake

8. DANAHER MOTION made high-frequency cont roller incorporates a powerful microprocessor together with MOSFET power electronics.

Specifications of SINOLIFT 4-wheel AC 4.0-5.0T Electric Forklift
Specification	Manufacturer		SINOLIFT 4-wheel AC 4.0-5.0T Electric Forklift
	Model			CPD40JD1	CPD45JD1	CPD50JD1
	Rated capacity		kg	4000	4500	5000
	Load center		mm	500	500	500
	Lifting height		mm	3000	3000	3000
	Free lifting height		mm	150	150	150
	Fork size	s×e×l	mm	50×150×1070	50×150×1070	50×150×1070
	Tilting angle	F/R	Deg	6/12	6/12	6/12
Dimensions	Overall Dimension	Length to face of fork	mm	2965	3015	3015
		Width	mm	1380	1380	1380
		Height when mast lowered	mm	2185	2185	2185
		Height when mast lifting	mm	4117	4117	4117
		Height to safeguard	mm	2310	2310	2310
		Height seat	mm	1185	1185	1185
	Turning radius	Min.	mm	2600	2600	2650
	Overhang	Front	mm	550	550	550
	Thread(Front/Rear)		mm	1130/1100	1130/1100	1130/1100-
	Ground clearance	Min.	mm	219	219	219
	Wheelbase		mm	2000	2000	2000
	Fork spread	Min./ Max.	mm	310/1200	310/1200	310/1200
	Working aisle width with pallet (Ast*)	1000×1200 crossways	mm	4516	4566	4566
	Working aisle width with pallet (Ast*)	800×1200 lengthways	mm	4615	4665	4665
Performance	Speed	Travel (Laden)	km/h	14	13.5	13
		Travel (Unladen)	km/h	14	13.5	13.5
		Lifting (Laden)	mm/s	270	260	250
		Lifting (Unladen)	mm/s	430	420	400
		Lowing (Laden)	mm/s	410	410	410
		Lowing (Unladen)	mm/s	420	430	440
	Gradeability	Laden	%	14.5	14	13
	Gradeability	Unladen	%	15.5	15	14
	Max. Drawbar pull	Laden (S2 5min)	N	24000	26000	27000
	Service weight	include battery box	kg	6600/14520	6800/14960	6950/15290
	Axle Loading (Front/Rear)	Laden	kg	9440/1160	9950/1350	10635/1315
	Axle Loading (Front/Rear)	Unladen	kg	3960/2640	3950/2850	3475/3475
	Tyre	Front×2		250/15	250/15	250/15
	Tyre	Rear×2		7.00-12	7.00-12	7.00-12
Driven	Motor	Driven motor ×2	kw	16.6	16.6	16.6
	Motor	Pump motor	kw	25.4	25.4	25.4
	Battery	Standard	V/AH	80/700	80/700	80/700
	Battery weight include box (STD. Battery)			2100	2100	2100
	Controller	Type		MOSFET	MOSFET	MOSFET
	Controller	Manufacturer		Danaher Motion	Danaher Motion	Danaher Motion
	Operating pressure for attachment		Mpa	17.5	17.5	17.5
	Noise level		dB(A)	74	75	76
	Note:
	1. CPD-J series means AC system (Traction AC+ Pump AC).
	2. Special lifting height available.
	3. Attachment available.
	4. The specification in the table are for standard models only. For further information please contact us .
	5. Specification are subject to change without notice.
