العربيةCDD10-080 CDD10-090 Economic Power Stacker
WS08-10 Cap.1000KGS Mono Mast Electric Stacker
WS08-10 is the light-duty economic electric stacker, equipped with DC driving system and electromagnetic brake. Without electric power steering system but longer handle design, still very easy to operate.
1. Strong H profile mast, stronger mast make lifting to be safe and fluent with more capacity;
2. Steel cover: one piece steel cover, which reduce the cover damage greatly;
3. One piece fork: with 8mm to 10mm thickness. Liftstar proudly declare that there are no possibility of deformation under high frequency using;
4. Two pieces dismountable handle tube, made from high quality mold, which make assembly and dismantle of handle tube to be much easier;
5. Driving controller: Curtis 1243 controller can be programmed by Curtis Hand Set easily;
6. Longer handle design: very light and easy turning design which is very comfortable.
| Model | CDD10-080 | CDD10-090 | |
| Mast | Duplex | Duplex | |
| Fork leg | Fixed leg | Adjustable straddle leg | |
| Capacity | kg | 1000 | 1000 |
| Load center | mm | 600 | 600 |
| Lifting height | mm | 1600/1950 | 1600/1950 |
| Fork length | mm | 1150(1220) | 1070 |
| Fork width | mm | 185 | 100 |
| Outside width of forks | mm | 550/600/650/685 | 200-812 |
| Inner width of forks | mm | 180/230/280/315 | 0-612 |
| Travel speed | km/h | 3 laden/3.5 unladen | 3 laden/3.5 unladen |
| Lift speed | mm/s | 130/230 (laden/unladen) | 130/230 (laden/unladen) |
| Lowering speed | mm/s | 130/230 (laden/unladen) | 130/230 (laden/unladen) |
| Drive motor | kw | DC0.63 | DC0.63 |
| Lifting motor | kw | DC2.0 | DC2.0 |
| Battery | V/Ah | 12V/70Ah*2 | 12V/70Ah*2 |
